This robust gantry crane operates on fixed rails, providing exceptional stability and precise positioning for stacking containers, loading and unloading trains and trucks, and organizing yard storage with maximum space utilization.
Key Features & Technological Advantages
1. Robust Structural Design
- Optimized Box Girder Construction: The main girder and leg structures are fabricated from high-strength, low-alloy steel using advanced finite element analysis (FEA). This ensures superior structural integrity, minimal deformation under full load, and an extended service life, even in the harshest environments.
- Dual-Girder Configuration: Standard dual-girder design provides unmatched lifting stability and higher crane hook height, essential for handling containers in multiple stacked rows.
2. High-Precision Hoisting System
- Powerful and Efficient Lifting: Equipped with high-torque hoisting motors, precision gearboxes, and fail-safe disc brakes. The system ensures smooth, responsive, and reliable lifting and lowering operations with pinpoint accuracy.
- Spreader Options: Compatible with a variety of spreaders, including 20ft, 40ft, 45ft telescopic models, and optional rotator spreaders for handling both standard and special containers.
3. Smooth and Reliable Travel System
- Rail Travel (Gantry Motion): The crane travels on heavy-duty steel rails via driven bogies on each leg. The system is synchronously controlled to prevent skewing and ensure straight, smooth travel across the entire yard.
- Trolley Traverse: The trolley moves seamlessly along the main girder on hardened steel rails, allowing for precise cross-positioning of containers. Anti-sway technology is integrated for safe and efficient load transfer.
4. Advanced Control & Automation (Optional)
- Ergonomic Operator Cabin: A fully equipped, climate-controlled cabin offers excellent visibility, reduced noise levels, and intuitive controls, significantly enhancing operator comfort and productivity.
- Intelligent Control System: Featuring variable frequency drive (VFD) control for all motions, ensuring soft starts and stops, precise speed regulation, and substantial energy savings.
- Automation Ready: Weihua RTGs can be equipped with state-of-the-art automation packages, including:
- Automatic Stacking: For unmanned container storage and retrieval.
- Position Detection System: Uses lasers and GPS/RFID to identify container locations accurately.
- Remote Control: Allows operators to control the crane from a remote station.
- Collision Avoidance Systems: Enhances safety for both equipment and personnel.
5. Energy Efficiency & Sustainability
- Regenerative Drives: The VFD system can feed energy generated during lowering and braking back into the power grid, drastically reducing overall energy consumption.
- Eco-Friendly Options: Electric power supply is standard, eliminating on-site emissions. This makes it the ideal solution for environmentally sensitive areas and indoor terminals.
6. Safety & Reliability
- Comprehensive Protection: Equipped with overload limiters, height limiters, travel limit switches, anti-wind devices, and emergency stop systems.
- Robust Construction: All critical components, from wire ropes to electrical systems, are selected from internationally renowned brands (e.g., Siemens, Schneider, ABB, SEW) to guarantee maximum uptime and reliability.
Technical Parameters (Standard Model – Customizable)
| Parameter |
Specification |
| Lifting Capacity |
30.5 / 35 / 40 / 50 / 60 tons (under spreader) |
| Span |
20m – 50m (Customizable to your yard layout) |
| Lifting Height |
15m – 25m (Above rail top) |
| Lifting Speed |
Full Load: 15-25 m/min |
| Trolley Travel Speed |
40 – 70 m/min |
| Gantry Travel Speed |
50 – 90 m/min |
| Power Supply |
380V/50Hz or 480V/60Hz, 3 Phase. Slip-ring or cable reel system. |
| Control Mode |
Cabin Control + Remote Control (Ground Pendant) + (Optional) Full Remote/Auto |
| Stacking Capability |
Typically 4-over-1 or 5-over-1 (depending on configuration) |
| Rail Gauge |
Customizable (e.g., 6m, 10.5m, 16m, 35m) |
Rail-type Container Gantry Crane Applications
| Port Container Terminals |
Moving containers between storage yards, ships, and trucks |
| Railway Intermodal Terminals |
Efficiently loading and unloading containers from freight trains |
| Logistics Parks and Depots |
For container storage, consolidation, and inspection |
| Industrial Plants |
Handling containerized raw materials or finished goods |
Why Choose Weihua?
- 1. Global Experience: Weihua has installed thousands of units worldwide, understanding diverse operational challenges.
- 2. Customized Solutions: Every crane is engineered to meet your specific yard layout, operational workflow, and capacity requirements.
- 3. Quality Assurance: From raw material to finished product, every step is governed by strict ISO quality control protocols.
- 4. Comprehensive Support: We provide complete after-sales service, technical support, and a global supply of genuine spare parts.
Contact Us Today
Elevate your terminal’s operational efficiency and handling capacity with the robust and intelligent Weihua Rail-type Container Gantry Crane. Our engineering team is ready to design the perfect solution for your business.
