This robust gantry crane excels in efficiently loading/unloading vehicles (cars, trucks, SUVs, buses) directly onto/off Roll-on/Roll-off (Ro-Ro) vessels, barges, and ferries, while also being perfectly suited for maneuvering heavy machinery, containers, and general cargo within port terminals, vehicle processing compounds, and shipyards. It’s the ultimate solution for operations requiring rapid, safe, and precise material movement across both maritime and automotive environments.

Automotive Marine Gantry Crane Key Features & Benefits

• 1. Dual-Environment Mastery:

  • Marine Grade Construction: Fabricated from high-tensile steel with advanced corrosion protection (e.g., galvanization, specialized marine-grade coatings – C5-M standard) to withstand harsh saltwater, humidity, and coastal weather conditions.
  • Automotive Handling Precision: Engineered for the delicate yet heavy task of lifting vehicles without damage. Features smooth hoisting and traversing controls, anti-sway technology, and specialized lifting attachments (see below).

• 2. Robust Lifting Capacity: Engineered for demanding tasks, with standard capacities ranging from 20 tons to 150+ tons, capable of handling multiple vehicles simultaneously, heavy machinery, or large containers with ease.

• 3. Specialized Lifting Attachments:

  • Multi-Vehicle Lifting Frames (Spreaders): Adjustable spreaders designed to securely lift multiple standard passenger vehicles or light trucks (e.g., 2, 4, or 6 vehicles per lift) by their manufacturer-approved lift points (wheel cradles, axle supports).
  • Single-Point Lifting Hooks: For versatile handling of individual heavy vehicles, machinery, or general cargo.
  • Container Spreader Compatibility: Optional twist-lock spreaders for handling standard ISO shipping containers (20ft, 40ft, 45ft).
  • Customizable Crane Hook & Slings: Configurable for specialized loads or equipment.

• 4. Wide Span & High Lift:

  • Large Span: Clear spans designed to cover multiple lanes of vehicles, Ro-Ro ship decks, or work areas (typical spans: 15m to 40m+).
  • Significant Lifting Height: Provides ample hook height to lift vehicles over ship rails, stacked containers, or onto multi-level transporters.

• 5. Enhanced Mobility & Flexibility:

  • Rail-Mounted: Ensures precise, straight-line movement along dedicated tracks for efficient yard organization and vessel alignment. Heavy-duty rails and bogies provide stability under load.
  • Rubber-Tired (Optional): Offers greater flexibility for operations needing relocation across hardstand areas without fixed rails (requires suitable ground conditions).
  • Long Travel & Cross Travel: Smooth, variable-speed travel motors allow precise positioning over vessels, trucks, and storage areas.

• 6. Advanced Control & Safety:

  • Operator Cab: Ergonomically designed, climate-controlled cab with panoramic visibility, equipped with intuitive joystick controls, load moment indicator (LMI), and comprehensive crane management system (CMS).
  • Radio Remote Control: Allows safe and flexible operation from the optimal vantage point, especially crucial near vessel edges or in congested areas.
  • Critical Safety Systems: Overload protection, emergency stop buttons, limit switches for hoist and travel, anti-collision systems, wind speed indicators, and robust braking systems.
  • Lighting & Signaling: Integrated work lights and audible alarms for safe operation in low visibility or noisy environments.

• 7. Durability & Low Maintenance:

  • Heavy-duty construction throughout (girders, end carriages, hoisting machinery).

  • Sealed and lubricated components for marine environments.

  • Easy access points for inspection and maintenance.

Automotive Marine Gantry Crane (HD-AMG Series) – Technical Specifications

All values customizable to project requirements

Notes & Customization:

• 1. Duty Cycle: Configurable for light (A3) to severe (A7) service per FEM/ISO standards.
• 2. Automation: Optional AIV (Automated Guided Vehicle) integration for autonomous logistics.
• 3. Dimensions/Weight: Site-specific engineering for foundation/space constraints.
• 4. Reporting: IoT-enabled for real-time load data, maintenance alerts, and operational analytics.

Automotive Marine Gantry Crane Applications

• 1. Loading/Unloading vehicles (cars, vans, trucks, buses) onto/off Ro-Ro vessels, barges, and ferries.

• 2. Vehicle processing yards and storage compounds within ports.

• 3. Moving heavy machinery, construction equipment, and project cargo in ports and shipyards.

• 4. Container handling in smaller terminals or specialized areas.

• 5. Shipbuilding and repair yards for component handling.

• 6. Heavy industrial plants requiring versatile overhead lifting near waterfronts.

Why Choose Our Automotive Marine Gantry Crane?

• 1. Unmatched Versatility: Seamlessly handles the unique demands of both automotive logistics and marine cargo.
• 2. Superior Durability: Built to last in the harshest coastal and industrial environments.
• 3. Operational Efficiency: Maximizes throughput for vehicle handling and general cargo with smooth, precise, and powerful operation.
• 4. Enhanced Safety: Comprehensive safety features protect personnel, cargo, and equipment.
• 5. Customizable Solutions: Engineered to meet your specific span, height, capacity, and operational requirements.
• 6. Proven Reliability: Backed by robust engineering and quality manufacturing.

Invest in the HD-AMG Series for a seamless, efficient, and powerful solution bridging your landside automotive operations and maritime logistics. Contact us today for a detailed consultation and quote tailored to your specific needs.
